The EuropeLift TM3620A is a compact articulated tracked aerial lift designed for elevated access in tight or hard-to-reach job sites. Powered by a dependable Honda gasoline engine with DC battery backup, the TM3620A delivers smooth hydraulic operation, excellent outreach, and advanced outrigger safety systems, making it ideal for maintenance, tree work, construction, and facility applications.

• Maximum Working Height: 43 ft
• Maximum Platform Height: 36 ft
• Maximum Horizontal Outreach: 20 ft
• Platform Capacity: 485 lbs
• Articulated Telescopic Boom
• Jib Length: 4 ft
• Fly Jib Articulation: 145°
• Rotation (Non-Continuous): 355°
• Gradeability: 8%

• Platform Dimensions:
  • 3 ft 11 in × 2 ft 7.5 in × 3 ft 7 in
• Platform Rotation: 2 × 45°
• Aluminum Platform Basket
• Optional Hydraulic Platform Rotator

• Honda Gasoline Engine
• DC Battery Power Source
• Fully Hydraulic Controls

• Hydraulic Outriggers
• Ground Pressure Sensors on All Outrigger Plates
• Audible & Visible Outrigger Safety Alarms
• Hour Meter
• Manual Recovery Hand Pump
• Automatic Reverse & Overrun Brakes
• Handbrake System
• Outrigger Cylinder Rod Covers

• Transport Length: 21 ft
• Transport Width: 5 ft
• Transport Height: 6 ft 11 in
• Gross Weight: 3,262 lbs
• Outrigger Footprint: 11 ft

• Tree trimming
• Building maintenance
• Indoor & outdoor elevated access
• Sign installation
• Facility maintenance
• Construction access work
